NOTE: These are pictures taken June 06, 2000 at the Redding Jet Center, near the Redding Airport during a visit by these two aircraft sponsored by the Collings Foundation.

The Webmaster collects the Radio Equipment that was used in these aircraft. SCR-274N and ARC-5. He has several working units that he uses on the Amateur Radio Bands to communicate with and listen to Short Wave Broadcasting.

CLICK HERE to Contact the Webmaster

WARBIRDS AT REDDING JET CENTER

Many thanks to those that coordinated this visit of the two "Warbirds". It has been about 15 years since I stood next to a B-17. I remember clearly the sight and sound as the engines were started...I can still smell the oil and feel the rush of the air from the prop wash. I will never forget the sound of those radial engines.

PHOTOS OF THE B-17

WW2 B-17 Bomber Views

This is a side view of the B-17 fronting the Redding Jet Center.

This is Greg shortly after he learned that the Radio-Operator/Gunner position had been filled...oh well...

This is the front nose area of the B-17. The Navagation and Bomb Sighting was done from this area. The machine guns are also seen.

This is the nose of the B-17.

This is the very narrow catwalk in the Bombay area of the B-17.

The machine gun is located on the left, and the ball tourett is in the rear floor.

B-17 Liason and Command Radio System Equipment

This is a replica radio operator's position. The BC-348 Radio Receiver is shockmounted on the table top, with the BC-456 AM Modulator mounted above.

This is Liason Transmitter, type BC-375. On left are the plug-in coil boxes. The Antenna Tuner is above the Transmitter itself on the right.

This is part of the Command Radio system of the B-17. A two transmitter rack is mounted above the 3 receiver rack.

This is another view of the communications equipment.

This photo identifies some of the components of the radio system.

B-17 Cockpit area

This is the left seat of the B-17.

These are some of the engine and other controls of the B-17.

This is view forward from the B-17 cockpit, the sky is the limit.

PANORAMIC IMAGES OF B-17 BOMBER

This is a side view of the B-17.

This is a side view of the B-17.

This is a rear view of the B-17.

This is a rear view of the B-17.

This is a side view of B-17.

This is a side view of B-17.
